VRF Heat Recovery Air Source Outdoor Unit

6-36 Ton Heat Recovery Systems (208/230V, 460V, 575V)

The YORK® VRF Heat-recovery Outdoor Unit offers an extended operating temperature range and can heat and cool spaces simultaneously.

Back to Top

Efficient, Cost-effective Comfort

YORK® Variable Refrigerant Flow (VRF) Heat-recovery Outdoor Units offer an extended operating temperature range: outdoor ambient temperature as low as -4°F (-20°C) in the cooling mode, utilizing a low ambient kit, and as low as -13°F (-25°C) in the heating mode. The simultaneous heating and cooling operating range of this VRF system is from -4°F to 75°F. Redesigned inverter scroll compressors, dual inverter compressors and power-saving demand control deliver efficient performance that translates to significant cost savings.

Download VRF Catalog
Businesspeople discussing in a meeting in office

Benefits

DESIGN FLEXIBILITY

Up to 3,281 feet total pipe run and a vertical lift of 360 feet provide outstanding design versatility.

EXCEPTIONAL ENERGY EFFICIENCY

Redesigned inverter scroll compressors deliver optimum efficiency at partial load conditions.

GREATER PROJECT OPPORTUNITY

Impressive operating ranges and high capacities at low and high ambient temperatures meet diverse application requirements.

Features

  • Single-chassis units in 6, 8, 10, 12, 14 and 16 Tons enable system designs with fewer units and system sizes up to 36 tons
  • Dual-inverter compressors standard in 8, 10, 12, 14 and 16 Ton units for increased efficiency
  • Advanced defrost cycle operation in the heating mode
  • Long refrigerant piping lengths provide design flexibility – up to 3,281 feet total pipe run and a vertical lift of 360 feet when the outdoor unit(s) is above the indoor unit(s)
  • Connection ratios up to 150% provide more design options
  • Power-saving demand control for reduced peak load and energy savings
